Features of screw press dewatering machine
1, Wide application scope: suitable for fruit and vegetables juicing, as well as roots, stems, flowers and other plantings, beer residue, grain residue, coffee residue, wastes dewatering treatment, ect.
2, Equipped with internal propeller, it not only prevent material returning, also also play a minor role in crushing
3, It consist of screw conveyor and screw press, squeezing more thoroughly.
4, Equipped with internal stirrer, ensuring stirring and squeezing, preventing the phenomenon of “inner wet, outer dry”.
5, Stainless steel triangular wedge filter screen with high strength, abrasion resistance, durability, corrosion resistance, long life, few filter clogging, with good filtration.
6, Simple structure, low speed, high torque, low noise, no vibration, less wearing parts, low maintenance costs.
Model | YH120 | YH180 | YH550 | YH650 |
Capacity | 500-800kg/h | 1500-2000kg/h | 5000kg/h | 10T/H |
Voltage | 380V/50HZ/ 3 phases or according to your requirements | |||
Power | 4kw | 7.5kw | 18.5kw | 30kw |
Lenght of screw | 120mm | 180mm | 550mm | 650mm |
Weight | 200kg | 300kg | 2600kg | 3300kg |
Dimension | 1900*550*750mm | 2400*600*1150mm | 4500*920*1700mm | 5500*1000*1870mm |
Application of screw press dewatering machine:
1, Juicing of fruit and vegetable, as well as roots, stems, flowers and other plantings.
2, Dehydration of various waste residue: for example, coconut husk, the herb dregs, tea leaves, vinegar husk,
beer husk, cassava residue, coffee residue, etc.
3, Dewatering of food waste, garbage, kitchen waste, and separation of organic and inorganic substances.
4, Dehydration of various dung, such as pig manure, cow dung, duck droppings, etc.
