Application:
This machine is Suitable for package of foodstuff, seasoning, medicine (For example:ncutlet, peanut, tea, candy,non-sticky powder, mushroom, potato chips and so on.
Characteristics:
This Packing machine can automatically complete a series of actions, such as bag making, the measuring,filling, inflating, counting, sealing, code printing, material giving,
stopping in certain quanting, fixed-bag cutting and same cutting.
| Model | YH-320LD |
| Packing speed | 50-80bags/min |
| Packing range | 50-400ml |
| Film width | ≤ 320mm |
| Making bag size | L: 50-200mm, W: 40-150mm |
| Packing accuracy | ≤ ±1% (depends on product) |
| Power supply | AC220V, 50/60Hz |
| Seal type | Pillow seal |
| Machine dimension | L 2000 × W800 × H1650mm |
Introduction:
This machine adpots correcting system controlled by microcomputer, owing to a response signal is handle and set pass through microcomputer it can accomplish whole set to synchronization, sack length, position fixing, voluntarily follow the tracks of light-mark and voluntarily diagnose trouble and show to screen.
This machine can automatically complete a series of actions, such as bag making, the measuring,filling, inflating, counting, sealing, code printing, material giving, stopping in certain quanting, fixed-bag cutting and same cutting. Suitable for package of foodstuff, seasoning, medicine (For example:ncutlet, peanut, tea, candy,non-sticky powder and so on.)
