Nut roaster machine
Application:
Application: roast, heat and dry the materials as follow:
Nut processing: sunflower seeds, peanut, chestnut, cashew nut, almond, walnut, etc.
Oil production line: sesame seeds, rapeseed, soya bean, peanut, sunflower seeds, etc.
Tea processing: tea leaf.
Chemical industry: heat and drying the chemical industry materials.
Condiments processing: chili, pepper, aniseed, etc.
Feed processing: fish feeds powder.
Grain processing: corn, broom corn, rice, millet, barley and wheat.
The technical parameters:
| Model | Capacity | Heating power | Motor power | Dimension(mm) | Roller size(mm) |
| YHCZ3-4 | 5-15kg/h | 0.6-3kw | 0.18kw | 730x510x800 | 300×400 |
| YHCZ3-6 | 10-20kg/h | 0.7-3.5kw | 0.18kw | 910x510x800 | 300×600 |
| YHCZ5-4 | 8-20kg/h | 1-5kw | 2kw | 930x660x1270 | 500×400 |
| YHCZ5-5 | 10-30kg/h | 1.5-7.5kw | 0.4kw | 1030x730x1300 | 500×500 |
| YHCZ5-10 | 30-60kg/h | 3-15kw | 0.4kw | 1580x750x1330 | 500×1000 |
| YHCZ7-10 | 50-250kg/h | 4-32kw | 1.1kw | 1650x950x1520 | 700×1000 |
| YHCZ7-15 | 100-350kg/h | 6-48kw | 1.5kw | 2000 x950x1520 | 700×1500 |
The advantage of roasting machine:
1.Protect environment: electromagnetism transform into heat energy to process the materials, carbon-free.
2.Save energy & low power consumption: roasting machine use the roller with the composite materials to decrease the energy lost. Heat efficiency95%, save 45% electricity.
3.Save electricity and time: the electromagnetism heating system make the roller heat by itself, without heat medium. Work 30seconds, the temperature can be 100 degree centigrade. Improve the working efficiency. Baking 5KG sunflower seeds cost 0.6KW/H, 5KGsesame seeds cost 0.55kw/h.
4.High temperature:Max.400 degree centigrade.
5.Human interface: humanization design, intelligent control. Easy to set up the parameter.
6.Temperature control accuracy: the temperature can control under±2%, make sure the quality
of roasted materials same each time, color is even. Low request to the workers, employee easy to
operate.
7.Self-diagnosis function, can show the problem on the display.
8.Good materials: made of food grade stainless steel, food grade, make sure the food is safe and
clean, up to GMP standard.
